Custom 72V 40Ah/ 60Ah/ 20Ah/ 30Ah/ 12Ah Electric scooter battery pack, scooter lithium battery, electric motorcycle, motorbike, moped battery, replacement battery for electric scooter, OEM/ODM
Bonnen Battery is an expert in scooter lithium battery manufacturer. We have successfully provided all kinds of replacement battery for electric scooter, electric motorcycle to the international markets for about 10 years. Bonnen electric scooter lithium batteries last for up to 8 years and do not require maintenance because we use NMC/ LiFePo4 pouch cells. These cells have longer life cycles and are safer than 18650 cells. No charging is needed, even if it sits in storage for 6 months. In addition, our electric scooter motorcycle battery pack are 80% lighter than traditional lead-acid components and use modern, more advanced technology.
| 72V 12AH | 72V 20AH | 72V 30AH | 72V 40AH | 72V 60AH | |
| Size(mm) | 53*207*380 | 75*209*396 | 178*172*290 | 200*200*270 | 178*172*290 |
| adjustable | (H*W*L) | (H*W*L) | (L*W*H) | (L*W*H) | (L*W*H) |
| Weight | 8kg | 12kg | 18kg | 22kg | 35kg |
| Continue power | 800W | 1200W | 2000W | 2500W | 4000W |
| Max power | 1600W | 2400W | 4000W | 5000W | 8000W |
| Working Volt | 60-84V | ||||
| Charging Volt | 84V | ||||
| Discharge End Volt | 60V | ||||
| Max Charge Current | 6A | 10A | 15A | 20A | 30A |
| Operating Temp | 0℃~45℃ Charging Operating -20℃~45℃ Discharging Operating |
||||
| Cycle life | 1500cycles @ 90% DOD | ||||
On the move economically, cleanly and conveniently with Bonnen scooter, motorcycle lithium battery.
Utilize NMC pouch battery technology to build a more compact E-scooter, motorcycle battery pack with long battery life.
Why the Lithium Battery is the Best Solution for E-Scooters and Motorcycles?
The advantages of lithium batteries over lead-acid batteries
1. Shorter charging time
Lead-acid batteries require 8-9 hours of charging while lithium batteries are 90% charged in two hours and only require three hours of charging.
2. It is not necessary to replace the battery
Lead-acid batteries are about 50% of their initial capacity after 1.5 years of use (about 400 cycles), but Bonnen solutions are about 80% after 8 years (about 1500 cycles). Due to the minimum required life for an E-scooter of three years, existing lead-acid batteries must be changed while lithium batteries do not.
3. More eco-friendly
The manufacturing process and even the disposal of lead-acid batteries can result in lead contamination. A lithium battery, on the other hand, contains no environmentally harmful material.
Advantages of lithium battery-operated scooters over engine-type scooters
1. E-scooters are almost maintenance-free
Unlike engines that need to be fueled and oil changed regularly, E-scooters require almost no maintenance after purchase.
2. Improve convenience of maintenance
Engine-type scooters require regular maintenance and additional checks, such as fueling, changing the oil, and changing the oil filter frequently, but electric scooters do not need this maintenance.
3. Ride eco-friendly
Scooters with motors emit toxic gases like CO, HC, and NOx. A scooter powered by electricity from a lithium battery, however, does not produce any emissions and is therefore safe for the human body and the environment.
Warnings
-
Never connect the positive and the negative of the battery with metal
-
Never ship or store the battery with metal
-
Never cut or puncture the battery
-
Do not expose the battery to water
-
Do not expose the battery to fire & high temperature
Storage &Non Use
-
Storage in a dry place with temperature of not exceeding 30°C
-
For long term storage keep battery charged 30%-50% of capacity
-
Do not storage battery with metal
-
Use terminal post covers to prevent any short circuit circumstance
