Project Description

  • Custom Battery Packs for Marine, Yacht, Boat 3KWH
  • Custom Battery Packs for Marine, Yacht, Boat 3KWH

3KWH Custom Battery Packs for Marine, Yacht, Boat

  • IP65 waterproof function

  • Continuous current 240A; peak current:650A; we adopt”relay” design

  • Battery module is designed according electronic automotive industrial shockproof level 8 standard

  • Can pass collision safety requirements (refer to ISO12405 standard)

  • Emergency start function

  • No protection circuit forcibly closed power supply function. That means: if there is any problem with the BMS, but the battery can still work if your boat is on the sea

  • Green Energy without contaminants

Request A Quik Quote
No.Item NameBasic parameter
1Nominal capacity240Ah
2Minimum capacity≥235Ah
3Watt hour3072Wh
4Nominal voltage12.8V
5Operating voltage range10V~14.6V
6Standard charging current120A
7Maximum continuous charge current250A
8Standard discharging method300A
9Maximum continuous discharge current300A; Max:370A(15S)
10Cycle life≥3500 cycles (80% DOD)
11Operating temperature-20~55℃
12Storage temperature-20~55℃
13Charging heatingYes
14Shipment voltage≥12.8V
15Communication modeCAN/RS485
16SizeL588*W210*H263(mm)
17Weight31kgs

Low cost
Lithium battery costs less over its entire lifetime.
Lightweight
Weighs 75% less than lead acid. Saves fuel when used in a vehicle or a boat.
Powerful
Able to deliver higher peak power for heavy loads than lead acid – continuous current as high as 250 A and surge current of 700 A.
Fast charging
Fully charges in 2 hours.
Long lifetime
Typically 4000 charging cycles, or more than 3 times the lifetime of lead acid.
High quality
Bonnen uses battery cells from the world leader CATL, and are backed by a 3-year warranty plus local after-sales service, ensuring trouble-free performance.
Built-in Battery Management System (BMS)
Ensures the safe operation of the battery by protecting it from overcharge, over-discharge and over current, thereby extending the lifetime of the battery
Battery monitoring
User can monitor the battery status through an LCD display or computer connection.
Convenient
Simple connections make lithium batteries easier to deploy and use.
Customizable
Bonnen can make a custom configuration to match your power, voltage and capacity needs.

L588*W210*H263(mm)

Warnings

  • Never connect the positive and the negative of the battery with metal
  • Never ship or store the battery with metal
  • Never cut or puncture the battery
  • Do not expose the battery to water
  • Do not expose the battery to fire & high temperature

Storage &Non Use

  • Storage in a dry place with temperature of not exceeding 30°C
  • For long term storage keep battery charged 30%-50% of capacity
  • Do not storage battery with metal
  • Use terminal post covers to prevent any short circuit circumstance

Additional Product Information

The Lithium battery makes every attempt to verify that its products are used and designed for your application. For additional questions or concerns, please contact with Bonnen or your distributor.
